Elinz 7" Monitor HD 12V 24V CCD 4PIN CCD 3 AV Inputs 600TVL Eyeball Reversing Camera Mini CMOS Truck Caravan

SKU: GEAR7ERV4PIN80010-BUDGCAR

7" Digital Screen w/ Sun Visor

High definition 800x480 with Sunshade design to avoid sun glare

CCD Image Sensor

Capture clear audio and sharp image or video footage with 120° wide view angle

3x10M Advanced 4 PIN Cables

Allows the monitor to power up the camerasno need to connect another power cable

New Upgraded Model

600TVL camera that provide high quality and clear images

3 AV Inputs

Can be connected up to 3 reversing cameras

IR Night Vision Camera

It comes with 18 IR LEDS to provide better night vision 120 degree wide field if view CCD camera

Heavy Duty 600TVL 4PIN Eyeball Reversing Camera

Powerful 12 LEDs for night vision.
Colour: White
120 degree wide vide angle
Clear view day or night
Colour infrared night vision waterproof CCD reverse camera

Mini CMOS 4PIN Camera

150 degreee wide angle view
Small colour mini camera which can be mounted easily on vehicle's bumper

Advanced 4 PIN Cable

Allows the monitor to power up cameras. No need to connect another power cable.
It comes with 2x 5 meters and 3x 10 meters 4PIN connecting cable.

For Buses, Trucks Heavy Vehicles

Reduce blind spots for larger vehicles and added safety

Built-in Light Sensor

The monitor will dim itself automatically at night to avoid glare

4 Angle Viewing Switch

Removable Sun Visor

Rotational Bracket

Built-in Loud Speakers

Monitor Parts & Labels

Wiring Labels

Product Dimensions

Remote

* No Batteries included

MORE INFORMATION

This 7” colour TFT monitor uses high definition colour LCD panel which offers almost 4 times more pixels than the other standard 7” screens. It has 3 AV inputs, 2 of which are sound enabled, which means that you can hook up the monitor to a DVD player., mp4 player etc. , to play video or hook it up to a reverse camera with microphone for better security.

It uses standard 4PIN connectors to connect to the cameras which will provide power to each camera attached. There are trigger wires with adjustable time delays on the inputs to enable indicators to be used to trigger an AV channel.

This 7” monitor reverse camera kit is suitable for 12V or 24V vehicle. It has voltage overload protection and reverse polarity protection to ensure the monitor and cameras are not damaged by fitting errors. It is mounted by a substantial U-bracket and sunshade to keep the sun off the monitor.

It has a stylish touch button control on the front panel of the monitor. It has a built-in light sensor with automatic adjustment, the monitor will dim itself automatically at night to avoid glare.

PRODUCT HIGHLIGHTS

High definition 800x480
- Pixels screen (2400Hx480V). Beware of other sellers claiming to sell 1440Hx234V screens. 1440Hx234V = 480x234 pixels = lower resolution screen.
Built in fusebox (No more messy box dangling on the dash)
3 AV inputs
- Can be connected up to 3 reversing cameras
Light sensor automatic adjustment
- Monitor will dim itself automatically at night no more manual adjustment when the screen gets too bright at night
Rotational bracket- Allow monitor to be mount on the dash roof of truck/caravan/car or anywhere that you find suitable
Monitor with 4 Angle viewing Switch
- Image can be adjusted for horizontal vertical mirror and normal viewing
This monitor reverse camera kit can be used with truck/caravan/bus/car
16:9/ 4:3 switch freely
Heavy duty night vision IR CCD Reversing camera
3x10M advanced 4 PIN cables
- Allows the monitor to power up the cameras no need to connect another power cable to camera (connect and disconnect the cables between your caravan/trailer easily)
Built-in loud speaker with AV-IN
3 ways video input and 2 ways audio input
Show rearview automatically when the reverse gear is engaged
Easy to install- You can DIY as long as you can locate your vehicle's 12V/24V power source
Industrial grade CCD camera
- High resolution wide field of view camera with in-built infrared LED night vision capability. Camera sun shade and base are constructed from a metal alloy shell to withstand vehicle shock and vibration
Heavy duty CCD camera
- Made to be powered on at all times ideal for viewing the rear image while in forward drive
- 600TVL Camera to show clear and sharp images
- 120 degree wide angle view
- IP67 waterproof withstands tough conditions (eg. bush travel)
- CCD image sensor (made by Sharp Company) – outputs digital signals that has better picture clarity, colour contrasting and sharpness.
- With 18 individual Infrared(IR) LED - it shows clear images in low light especially at night circumstances
- Hard metal cased waterproof and mudproof
- We are so confident with our reversing camera that we will provide 12 months replacement warranty if the reversing camera becomes faulty within the 12 months period
Heavy Duty 600TVL 4PIN Eyeball Reversing Camera
- Powerful 12 LEDs for night vision.
- Colour: White
- 120-degree wide video angle
- Clear view day or night
- Colour infrared night vision waterproof CCD reverse camera
Advanced 4 PIN Cable
- Allows the monitor to power up cameras. No need to connect another power cable.
- It comes with 2x 5-meter and 3x 10-meter 4PIN connecting cables.
Mini CMOS 4PIN Camera
- 150° wide angle view
- A small colour mini camera that can be mounted easily on the vehicle's bumper
Video : 3 Channel video input
- V1/V2/V3 - 1 AV input is connected to the reverse camera powered from the reverse light which will switch automatically when reverse gear is induced, the other AV input can be connected to another reverse camera *optional, powered by battery to show the rear image at all time, perfect for truck or caravan that need to monitor the rear al the time
Recommended for Buses, trucks, Heavy Equipment Vehicles
- This camera is a necessity. Mount at the recommended place and enjoy reversing without worries
Auto camera switch
- This system also comes with 3 trigger wires for cameras. Once a trigger wire is activated e.g. when the reverse gear is induced it will show the rearview automatically or when the vehicle is put on the turn Right signal the monitor will switch to the Right camera automatically to give clear view on the right side of vehicle before making a turn

ITEM DESCRIPTION

Screen Size: 7" Digital TFT panel with Sunvisor
Resolution: 800x480
Aspect Ratio: 16:9 image
Video Input: 3 way video input- 2 way audio input, with AV-IN
Power Supply: DC9V-32V
Recording time: 70 Min
System: PAL/NTSC Auto –Switching
Menu: OSD
Speaker: Built-in Loud speaker
Varying languages display
Bracket: with stand and U-shape bracket
Light Sensor: Automatic adjustment
Reverse Camera: CCD Camera18 IR LEDs, Night vision supported, Eyeball Reversing Camera 12 LEDs
Camera angle: 120° wide-angle view, Mini CMOS 4PIN Camera 150° wide-angle view
Resolution: 600TVL
IP67 waterproof
Hard metal cased waterproof
CCD image sensor (made by Sharp Company)
